DIVERSE SONIC RANGE, MAXIMUM DELAY POWER
Introducing the DD-8, the most wide-ranging and feature-rich BOSS compact series delay ever. This loaded pedal delivers more of everything—more great sounds, more delay time, more control options, and more connectivity. And it does it all in a standard BOSS pedal that slides easily into any mono or stereo setup. Eleven modes provide delay colors from basic to exotic, plus a looper with unlimited overdub capability and external control support. For maximum versatility in a minimum amount of space, there’s no better delay stomp than the DD-8.
SPECIFICATIONS
Nominal Input Level: -20 dBu
Input Impedance: 1 M ohm
Nominal Output Level: -20 dBu
Output Impedance: 1 k ohm
Recommended Load Impedance: 10 k ohms or greater
Bypass: Buffered bypass
Controls: MODE knob, TIME knob , FEEDBACK knob, E.LEVEL(Effect Level) knob, CARRYOVER switch, Pedal switch
Indicator: CHECK indicator (Used for indication of check battery)
Connectors: INPUT-A(MONO)/INPUT-B jack: 1/4-inch phone type, OUTPUT-A(MONO)/OUTPUT-B jack: 1/4-inch phone type, TEMPO/EXP jack: TRS 1/4-inch phone type, DC IN jack
Power Supply: Alkaline battery (9 V, 6LR61), AC adaptor (PSA series: sold separately)
Current Draw: 100 mA
Expected battery life under continuous use: Alkaline: Approx. 3.5 hours
*These figures will vary depending on the actual conditions of use.
Accessories: Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information"). Dry battery (9 V, 6LR61)
Options (sold separately): AC adaptor: PSA series, Footswitch: FS-5U, FS-6, FS-7, Expression pedal: FV-500H, FV-500L, EV-30, Roland EV-5
SIZE AND WEIGHT:
Width: 73 mm, 2-7/8 inches
Depth: 129 mm, 5-1/8 inches
Height: 59 mm, 2-3/8 inches
Weight (including battery): 440 g, 1 lb
