Features
- Provides guitarists with high-quality vintage tremolo effects in an easy-to-use compact pedal
- Dedicated "Wave," "Rate" and "Depth" knobs allow for precise effect tailoring
- "Rate" control allows for higher speed adjustment than classic PN-2
- "Wave" control alters LFO waveform from triangle to square
- "Depth" control determines the strength of the effect
- BOSS 5-year warranty
Specifications
- Nominal Input Level: -20 dBu
- Input Impedance: 1 M ohms
- Nominal Output Level: -20 dBu
- Output Impedance: 1 k ohms
- Residual Noise Level: -90 dBu (IHF-A Weighted, Typ.)
- Connectors: INPUT Jack, OUTPUT Jack, AC Adaptor Jack (DC 9 V)
- Power Supply: DC 9 V: Dry Battery 9 V type (6F22/9 V), AC Adaptor
- Current Draw: 20 mA (DC 9 V)
- Accessories: Dry Battery 9 V type (6F22/9 V)
- Option: AC Adaptor (PSA-Series)
- Width: 73 mm (2-7/8 inches)
- Depth: 129 mm (5-1/8 inches)
- Height: 59 mm (2-3/8 inches)
- Weight: 0.4 kg (0 lbs. 15 oz.)
- * 0 dBu = 0.775 Vrms
